Retaining Snap Rings

Rotor Clip Snap Ring External M60 Carbon Spring Steel Phosphate Rings on Wire DIN 471 Groove Depth D 1.50 mm Free Diameter Df 55.80 mm Groove Diameter Dg 57.00 mm Shaft Diameter Ds 60.00 mm Maximum Section S max 5.80 mm Thickness T 2.00...

Rotor Clip Snap Ring External M62 Carbon Spring Steel Phosphate Rings on Wire DIN 471 Groove Depth D 1.50 mm Free Diameter Df 57.80 mm Groove Diameter Dg 59.00 mm Shaft Diameter Ds 62.00 mm Maximum Section S max 6.00 mm Thickness T 2.00...

Rotor Clip Snap Ring External M63 Carbon Spring Steel Phosphate Rings on Wire DIN 471 Groove Depth D 1.50 mm Free Diameter Df 58.80 mm Groove Diameter Dg 60.00 mm Shaft Diameter Ds 63.00 mm Maximum Section S max 6.20 mm Thickness T 2.00...

Rotor Clip Snap Ring External M75 Carbon Spring Steel Phosphate Rings on Wire DIN 471 Groove Depth D 1.50 mm Free Diameter Df 70.50 mm Groove Diameter Dg 72.00 mm Shaft Diameter Ds 75.00 mm Maximum Section S max 7.00 mm Thickness T 2.50...

Rotor Clip Snap Ring External M160 Carbon Spring Steel Phosphate DIN 471 Groove Depth D 2.50 mm Free Diameter Df 151.00 mm Groove Diameter Dg 155.00 mm Shaft Diameter Ds 160.00 mm Maximum Section S max 12.20 mm Thickness T 4.00 mm Groove...
